MDS-M02 Radar Flowmeter

The MDS-M02 is a radar flow meter module that integrates liquid level measurement and flow velocity measurement based on microwave technology. It can be used for non-contact flow measurement in open channels, rivers, irrigation canals, underground drainage networks, flood control and early warning systems, and other applications. This product features low power consumption, compact size, high reliability, and easy maintenance; the measurement process is unaffected by factors such as temperature, sediment, river pollutants, and floating debris.

E-mail:info@madsurgroup.com

Send

Product Advantages and Features

1. Non-contact measurement, calculating flow rate based on cross-sectional parameters, unaffected by wind, temperature, fog, silt, floating debris, etc.
2. Applicable to various measurement conditions, outputting flow velocity, water level, and flow rate measurement data.
3. Low power consumption, compact size, high reliability, and easy maintenance.

Power Supply
ITEM.	Min	Typical	Max	Unit	Test Condition
Operating Voltage	9	12	24	V
Operating Current (Standard Version)	120	130	145	mA	12V
Operating Current (Low Power Version)	40	60	70	mA	12V
Operating Temperature	-45		85	℃
Baud Rate		115200		bps	Adjustable
Communication Method	RS485
Flow Velocity Radar Sensor
Measuring Range	0.1-20			m/s
Measuring Accuracy	±0.01			m/s
Resolution	0.01			m/s
Antenna Angle	12			deg
Transmit Frequency	24			GHz
Flow Direction Identification	Bidirectional Automatic Identification				Configurable Filter
Water Level Radar Sensor
Measuring Range	0.1-40			m
Measuring Accuracy	±5			mm
Resolution	1			mm
Antenna Angle	14			deg
Transmit Frequency	80			GHz
